LAUNCH ES200 EV Insulation Resistance Meter Tester

Insulation resistance meters are commonly known as megohm meters, or shake meters, high resistance meters, insulation resistance testers, etc. It is reflected by insulation resistance. The product insulation resistance which is measured refers to the insulation resistance between the live part and the exposed non-live metal part(case). Using an insulation tester for measurement can effectively protect the safety of maintenance personnel.

Product Features:

3. Three measurement modes: timing measurement, comparison measurement, continuous measurement and omnidirectional measurement.

Product Specification:

ES200 Specification

Battery: 3150mAh

Display: 5”

Working Temperature: 0~50℃

Dimensions: 180*174*65.5(mm)

Weight: 1.7kg

AC and DC Voltage Test Performance Parameters

Voltage Type                               DC Voltage                AC Voltage

Measuring Range                       ±30~±600V                30~600V(50/60Hz)

Resolution                                  1V                              1V

Measurement Accuracy              ±3%                           ±3%

Insulation Resistance Test Performance Parameters

Test Voltage:                      500V                                         1000V                                       2000V                                       5000V

Measuring Range:             0.0MΩ～20GΩ                          0.0MΩ～40GΩ                         0.0MΩ～100GΩ                        0.0MΩ～1000GΩ

Open Circuit Voltage:        DC500V(0～20%)                     DC1000V(0～20%)                   DC2000V(0～20%)                   DC5000V(0～20%)

Measurement Accuracy:    0.0～99.9MΩ: ±(3%+5)            0.0～99.9MΩ: ±(3%+5)             0.0～99.9MΩ: ±(3%+5)             0.0～99.9MΩ: ±(3%+5)

                                         100MΩ～9.99GΩ: ±(5%+5)      100MΩ～9.99GΩ: ±(5%+5)       100MΩ～9.99GΩ: ±(5%+5)      100MΩ～9.99GΩ: ±(5%+5)

                                         10.0GΩ～20.0GΩ: ±(10%+5)    10.0GΩ～40.0GΩ: ±(10%+5)    10.0GΩ～100GΩ: ±(10%+5)   10.0GΩ～99.9G: ±Ω(10%+5)
Short Circuit Current：    <3.0mA

Package includes:

1pc x LAUNCH ES200 EV Insulation Resistance Tester
